Jacobsen R-311T Parts & Maintenance Manual

113
> Change from previous revision
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
131717 8 Yoke, Caster Wheel Spindle
2 453022 AR Flat Washer, 3/4 x 1/8 Thick
3 3003207 10 Shaft, Caster Wheel
4 460056 10 Cotter Pin, 3/16 x 2”
5 403578 10 Screw, #10-24 x 1” Hex Head
6 446118 10 Lockwasher, #10
7 444310 14 Nut, #10-24 Hex
4185640 10 Caster Wheel, 11 x 4 x 5
8 148049 1 • Tire, 11 x 4 - 5NHS 4 Ply
9 363233 1 • Valve Stem
10 4185641 1 • Wheel and Bearing
4187500 1 • • Kit, Bearing & Bushing
11 4185642 2 •••Bearing, 1-3/8” OD Roller
12 4185643 2 •••Bushing, 1-3/8” Flanged
13 365772 32 Spacer, Cutting Height
14 361648 AR Washer
15 366593 24 Spacer, Caster Wheel
16 3004894 10 Pin, Klick Type
17 307374 AR Flat Washer, 3/4 x 5/64 Thick
