55
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
4172400 1 Front Axle
2 557623 2 Key
3 4167840 2 Hub, Wheel
4 4167841 2 Disc, Brake
5 400108 16 Screw, 1/4-20 x 3/4” Hex Head
6 557624 2 Nut
7 460093 2 Cotter Pin, 1/8 x 2-1/2”
8 4172601 1 Left Side Axle Support
9 4172600 1 Right Side Axle Support
10 400412 8 Screw, 1/2-13 x 2” Hex Head
11 453017 24 Flat Washer, 1/2
12 64229-05 18 Nut, 1/2-13 Nylock Hex Serial Number 69166-1656~1661
12 64229-05 12 Nut, 1/2-13 Nylock Hex
Serial Number 69166-1651~1655
Serial Number 69166-1662 and Up Serial Num-
ber 69167-All
13 400410 4 Screw, 1/2-13 x 1-3/4” Hex Head
14 4172901 3 U-Bolt Serial Number 69166-1656~1661
14 4204140 3 U-Bolt
Serial Number 69166-1651~1655
Serial Number 69166-1662 and Up Serial Num-
ber 69167-All
15 452012 6 Flat Washer, 1/2
16 4190744 2 Rim, Scrapper
17 400268 4 Screw, 3/8-16 x 1-3/4” Hex Head
18 4184644 1 Bracket, Floor Support
19 4190242 2 Mount, Step Support
20 4201700 2 Step Support, Right Side
21 400264 6 Screw, 3/8-16 x 1-1/4” Hex Head
22 452007 20 Flat Washer, 3/8
23 446142 10 Lockwasher, 3/8 Heavy
24 444762 10 Locknut, 3/8-16 Center
25 366292 2 Tire, 26 x 12 - 12, 6 Ply Multi-Trac
26 5002574 2 Wheel Rim, 12 x 10.5
27 360111 2 Inflation Valve
28 353914 12 Wheel Bolt, 1/2-20 x 3/4”
29 400276 2 Screw, 3/8-16 x 3” Hex Head
30 446140 2 Lockwasher, 3/8
31 452008 2 Flat WAsher, 3/8
32 4167723 1 Frame
33 163927 1 Pivot, Steering Axle
34 364830 3 Washer
35 445642 1 Nut, 1-1/2-12 Slotted Hex
36 460072 1 Cotter Pin, 1/4 x 2-1/2”
37 400266 1 Screw, 3/8-16 x 1-1/2” Hex Head
38 452006 1 Flat Washer, 3/8
39 446142 1 Lockwasher, 3/8 Heavy
40 443110 1 Nut, 3/8-16 Hex
41 REF 1 Steering Axle See 14.1
42 4197280 1 Bracket, Brake Cable
43 4201701 1 Step Support, Left Side
44 4204160 6 Locknut, 1/2-13 Hex
Serial Number 69166-1651~1655
Serial Number 69166-1662 and Up Serial Num-
ber 69167-All
