Jacobsen R-311T Parts & Maintenance Manual

59
> Change from previous revision
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
4185325 1 Steering Tower
2 4196200 1 Bracket, Steering Pump
3 3005934 2 Shoulder Bolt, 3/4-10
4 400258 2 Screw, 3/8-16 x 3/4” Hex Head
5 446142 2 Lockwasher, 3/8-16 Heavy
6 444849 2 Locknut, 3/4-10 Center
7 4197880 1 Steering Valve
4197940 1 • Seal Kit
8 443828 1 Nut, 5/8-18 Hex Jam
9 450191 4 Screw, M8-1.25 x 20 mm Hex Head
10 450411 4 Lockwasher, M8
11 450410 4 Lockwasher, M6
12 450171 4 Screw, M6-1 x 20 mm Hex Head
13 2811547 4 Washer, Steering Wheel
14 2811364 1 Steering Wheel
15 2811365 1 • Cover, Steering Wheel
16 447224 1 Lockwasher, 5/8 Internal Tooth
17 4184620 1 Shaft, Steering
18 5002918 1 Gas Spring
19 5002919 1 Cable, Actuator
20 416911 2 Screw, #10-24 x 1/2” Thread Cutting
21 400216 1 Screw, 5/16-18 x 2-3/4” Hex Head
22 400192 1 Screw, 5/16-18 x 1-1/2” Hex Head
23 444718 2 Locknut, 5/16-18 Center
24 367465 1 Bracket, Valve Mounting
25 132523 1 Valve, Weight Transfer
555862 1 • Cartridge, Valve
5003579 1 • Seal Kit
26 404022 2 Screw, 1/4-20 x 1” Truss Head
27 446130 4 Lockwasher, 1/4 Heavy
28 443102 4 Nut, 1/4-20 Hex
29 400120 2 Screw, 1/4-20 x 2” Hex Head
30 453023 2 Flat Washer, 1/4
31 5000917 1 Horn REFERENCE U9, See 60.1
32 400184 1 Screw, 5/16-18 x 3/4” Hex Head
33 446136 1 Lockwasher, 5/16 Heavy
34 452006 1 Flat Washer, 5/16
35 443106 1 Nut, 5/16-18 Hex
36 445245 8 Tinnerman Nut
37 404016 8 Screw, 1/4-20 x 5/8” Truss Head
38 4184622 1 Cover, Steering Tower
39 162739 1 Switch, Horn REFERENCE SW20, See 60.1
40 4192000 1 Decal, Weight Transfer
41 4182386 1 Decal, Jacobsen Emblem
42 4201840 1 Seal
