65
> Change from previous revision
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
4161120 1 Engine, Kubota V2203M
For complete listing of engine service parts,
See Engine Parts Manual
1
4200140 1 Engine, Kubota V2203M EC
4113986 1 • Engine Oil Filter
557619 1 • Cartridge, Fuel Filter
5000938 1 • Alternator REFERENCE U1, See 60.1
556988 1 • Starter REFERENCE M1, See 60.1
554018 1 • Engine Oil Pressure Switch REFERENCE SW17, See 60.1
556996 4 • Glow Plug REFERENCE R1, See 60.1
4134270 1 • Fuel Solenoid REFERENCE K13, See 60.1
l
4134323 1 • Belt, Fan
Used on engines with 3-7/8 in.
(99 mm) fan pulley only.
l
4202300 1 • Belt, Fan
Used on engines with 4-11/16 in.
(119 mm) fan pulley only.
2 338991 1 Pump Drive Flange
3 163916 1 U-Joint
4113644 1 • Yoke, Engine Side Flange
500562 2 • Cross Kit
4 362263 6 Screw, M10-1.25 x 25 mm Metric Grade 8.8
5 363485 6 Lockwasher, M10
6 400264 4 Screw, 3/8-16 x 1-1/4” Hex Head
7 446142 4 Lockwasher, 3/8 Heavy
8 443110 4 Nut, 3/8-16 Hex
9 366108 1 Bracket, Circuit Breaker Mounting
10 365980 2 Screw, M12-1.25 x 20 mm Metric Grade 8.8
11 446154 2 Lockwasher, 1/2 Heavy
12 361439 1 Circuit Breaker, 50 Amp Main REFERENCE CB6, See 60.1
13 361439 1 Circuit Breaker, 50 Amp Alternator REFERENCE CB7, See 60.1
14 402120 4 Screw, #10-24 x 5/8” Slotted
15 446118 4 Lockwasher, #10 Medium
16 444310 4 Nut, #10-24 Hex
17 367551 1 Switch, Temperature REFERENCE SW16, See 60.1
18 4199860 1 Fan, Suction
19 553174 1 Spacer, Fan
20 450012 4 Screw, M6-1 x 85 mm Flange
21 450410 4 Lockwasher, M6
l Before ordering belt, measure the diameter of the fan pulley. The two belts are not interchangeable.
