LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-11
* Not illustrated
1 MBF2423 Plate-Seat Mtg 1
2 2208058.07 Hinge-seat Plate 2
3 4125140 Wldmt-Tower 1
4 4125219 Wldmt-RH Frame Rail 1
5 4125141 Wldmt-LH Frame Rail 1
6 2216084 Wlmnt-Bulkhead 1
7 4125824 Fender-LH 1
8 4125825 Fender-RH 1 (Not Shown)
9 2212082 Back-Plate Fender 2
10 2212064 Cover-Access 1
11 4125225 Wldmt-Front Axle 1
MBF1988 Plate W/A 1
002989380 Trim Seal AR
12 450191 Scrw-hex M8 X 20 13
13 450390 Wshr-m8 X 17 X 1.8 8
14 148034-08 Insulated Grommet 1
15 450241 Screw-hex M12 X 30 16
16 450392 Wshr-m12 X 24 X 2.7 16
17 450380 Nut-hex M12 Nyloc 14
18 450193 Scrw-hex M8 X 30 3
19 001594010 Wshr-.328 X .75 X 14 Ga 18
20 450378 Nut-hex M8 Nyloc 17
21 W148034-01 Insul Grommet 1" I/D 1
22 450214 Scrw-hex M10 X 25 4
23 450391 Wshr-m10 X 21 X 2.2 8
24 450379 Nut-hex M10 Nyloc 4
25 64061-04 Roll Pin-1/8x3/4 2
26 W143036a Rod-support 1
27 W138040 Clip-hood Rod 1
28 001393400 Nut-hex #6-32 Keps 4
29 MBG3817 Brkt-rod Clip 1
30 64152-21 6-32x1/2lg Rd Hd Sc 4
31 48228-05 Clip-cable,Insulated 1
32 001399121 Nut-hex 1/4-20 Nyloc 1
33 456110498 Scrw-hex 1/4-20 X 1/2 1
34 2218084 Grommet 1
35 452200176 Lockwshr-1/2 X .873 X .125 2
36 2212245 Bracket-deck Stop 2
37 523126 Bumper-rubber 2
38 001393010 Nut-hex 5/16-18 Whiz 2
39 450453 Nut-hex M8 Verbus Ripp 4
40 MBA5289A Wshr-8.5 X 25.5 X 3 4
41 450192 Scrw-hex M8 X 25 4
42 2720289 Assy-m12 Bolt W/Lanyard 2
4 FRAME - FRONT
