GB-3
FRONTLINE 960 Series: LQ
MAINTENANCE AND PARTS MANUAL
GB
2 INTRODUCTION
2.3 HOW TO USE THE PARTS MANUAL
ITEM NUMBER
Each part which is identified in the illustrations has an item number. Parts which do not have an item number
may not be readily identified in the illustration but are usually closely associated with the immediately adjacent
part.
ASSEMBLIES
A complete assembly, e.g. a wheel motor or hydraulic motor or roll assembly, is listed as a complete item with
subsequent individual components listed separately.
The assembly is listed under it's part number with component parts being listed offset to the right, e.g:-
ITEM RANSOMES DESCRIPTION QTY REMARKS
PART NO.
4295 MBG2504 BRACKET 1
4296 MBG3848 LATCH 2
4298 450865 SCREW, M8 x 20, SCKT CSK HD 2
4300 450378 NUT, M8 NYLOC 2
4301 Wl001 Set Of Wheels 1
4301.1 008162130 • Wheel & Hub Assy 1 (Rear)
4301.2 008170390 • • Tyre 1
4301.3 008161830 • • Rim 1
4301.4 008169140 • • Hub Assy. 1
4301.5 008169150 • • Cap 1
4301.6 002993010 • • Lubricator 1
4301.7 008161990 • Wheel & Tyre 2 (Front)
4301.8 008170780 • • Tyre 2
It may not be possible to illustrate every item. With certain items purchased from outside suppliers some
component parts may not be available from Ransomes and may need to be specially ordered from the supplier.
QUANTITIES
Quantities shown are for one assembly or sub-assembly.
USING THE PARTS LIST
Determine the function and application of the part required. Turn to the main index page and select the
appropriate section. Locate the part on the illustration and parts list and read off the quantity from the
appropriate MODEL column.
NUMERICAL INDEX
This is a summary of all part numbers used in the manual arranged in numerical sequence and showing the
page and item number under which the parts appear.
ORDERING OF SPARE PARTS
When ordering replacement parts, it is most important to quote the SERIAL NUMBER of the machine, PART
NUMBER, DESCRIPTION and QUANTITY required.
Spare Parts can also be ordered direct from the TEXTRON DIRECT web site at www.textrondirect.com
Any arbitrary modifications carried out on this machine may relieve the manufacturer of liability for any resulting
damage or injury.
ABBREVIATIONS
N/A Not Available
AR As Required
