GB-7
FRONTLINE 960 Series: LQ
MAINTENANCE AND PARTS MANUAL
GB
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION
TYPE: Perkins 45KW (60HP) @ 2800
RPM, 4 cylinder (in line) vertical
Diesel engine, 4 stroke, water
cooled, 2200cc (135.2 cu.in)
with 12V electric start.
Model: 404C-22T
Maximum Speed: 3000 ± 25 RPM (No load)
Idle Speed: 1250 ± 50 RPM
Oil Sump Capacity:10.6 litres (18.65 Imp.pints)
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION
Frame construction:Heavy duty formed steel chassis
with box section frame rails.
Cutting unit drive: Fixed displacement hydraulic
motors coupled to cutting means
through drive belt.
Transmission: Full time 4-wheel drive. Direct
coupled variable displacement
pump to direct coupled 280cc
(17.1 cu in) front, 237cc (14.5 cu
in) rear wheel motors.
Speeds:
Cutting: 0 - 12km/h (0 - 7.5 mph)
FORWARD
Transport: 0 - 22km/h (0 - 13.7mph)
FORWARD
Reverse: 0 - 12km/h (0 - 7.5 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Tyres:
Front - Front - 24 x 13 - 12 4 ply rating
turf
Rear - Rear - 20 x 10.00 - 8 6 ply rating
turf
Pressures: Front tyres
20 p.s.i. (1.4 kg/cm
2
)
Rear tyres
14 p.s.i. (1 kg/cm
2
)
Ground pressure: 14p.s.i. (1 kg/cm
2
)
Brakes, Service: Positive hydrostatic braking.
Parking: Fail safe, Oil immersed wet disc
brakes.
Fuel Tank
Capacity: 45.4 litres (10 Imp. galls) 12 US
galls
Hydraulic Tank
Capacity: 18.8 litres (4.14 Imp. galls) 5 US
galls
Battery: Exide 065
4.3 DIMENSIONS
Width of cut:
9'8" Model 2.95 metres (116in)
10'7" Model 3.23 metres (127in)
Overall width: metres (in)
Overall width: 1.55 metres (61in)
(transport)
Overall height: 1.35 metres (53in)
Overall length: 3.1 metres (122in)
Overall weight of
machine:
9'8" Model 1554 kg (3426 lb)
10'7" Model 1577 kg (3476lb)
4.4 VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Standard ISO 5349: 1986 Mechanical vibration.
Guidelines for the measurement and the
069ENILTNORF
QLseireS
noitareleccAmrA/dnaH
level
HRroHLxaM
s/msnoitareleccA
2
qeAXqeAYqeAZ
46.033..091.0
eulaVtnanimoD46.0
assessment of human exposure to hand-transmitted
vibration.
Standard ISO 2631-1: 1985 Evaluation of human
ENILTNORF
069
QLseireS
ydoBelohW
noitareleccA
level
noitacoLroolF
s/msnoitareleccA
2
noitacoLtaeS
s/msnoitareleccA
2
xyzxyz
naeM60.050.081.050.050.020.0
exposure to whole body vibration -- Part 1: General
requirements.
4.5 SLOPES
DO NOT USE ON SLOPES GREATER THAN 15°
The slope 15° was calculated using static stability
measurements according to the requirements of
EN 836.
To Next Page
