106
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM
PART NO DESCRIPTION PAGE ITEM
960 FRONTLINE
PARTS MANUAL
38383 SWITCH-N.C. 43 17
46335 SHAFT ASM-ROLLER 97 25
46335 SHAFT ASM-ROLLER 103 *
48378 STRAP- RUBBER 49 45
48383 HOSE CLAMP SIZE 32 9 *
48383 CLAMP-HOSE SAE32 73 F213
48383 CLAMP-HOSE SAE32 77 F213
48383 CLAMP-HOSE SAE32 81 F213
48396 HOSE CLAMP SIZE 24 9 *
48396 CLAMP-HOSE 2 DIA 47 30
48396 HOSE-CLAMP SAE24 73 F214
48396 HOSE-CLAMP SAE24 77 F214
48396 HOSE-CLAMP SAE24 81 F214
48408 FLASHER-552 12V 45 64
48429 SPRING-EXTENSION 61 58
48524 CIRCUIT BREAKER 40A 83 22
58026 3 WAY CONNCTR 1/4 33 23
64205.03 BLT MET M6X1.00X40 37 43
128079 ROD END, 1/4 FEMALE 37 20
128079 ROD END, 1/4 FEMALE 43 11
142064 PLATE-BACKING 97 6
142088 BRKT-ROLLER 97 *
142108.7 CAP-SPINDLE 105 13
143030 SPINDLE 105 7
143031 SPACER-SEAL 105 10
143032 SPACER-BEARING 105 8
146169 PULLEY IDLER W/BEARG 101 9
146197 WLDMT-PUSH ARM PIN 61 75
148027 BREATHER VENT 35 24
148070 BEARING-BALL 1-1/4 10 105 3
148081 GASKET 35 18
148090 SUPPORT-TUBE 1/2 35 36
172088.07 THROTTLE ARM 37 7
172212 BRKT-UPPER HANGER 49 45
172290 BRKT-LOWER HANGER 49 45
172298.07 SUPPORT-STEERING 45 45
172304.07 BRACKET-TILT WHEEL 43 37
173006 SHAFT-LOCKING 45 39
176100.07 WLDMT-FR WSHR 45 46
178007 BELT-CUTTER DECK(9'-8") 103 47
178024 FILTER HEAD MODULE 31 10
178024 FILTER HEAD 75 6 0
178025 FILTER-SPIN ON 31 9
178025 FILTER 75 61
178043.7 TUBE-FILTER HEAD 31 5
178045.7 SPRING-WING DECK 59 2 4
178100 VALVE-RH DECK 85 23
178100 VALVE-LH DECK 85 24
178138 WASHER-FRICTION 45 44
178145 BELT-CUTTER DECK(10'-7") 103 *
191160 HEX SCREW M14X30 FINE 19 3
838154 BRACKET, FUEL PUMP 7 72
839862 DECAL-STEERING WHL 45 75
2192486 BRKT-THROTTLE 7 48
2198084 LATCH-SWELL 43 *
2198109 KNOB-LEVER 39 1
2198125 BUMPER 43 *
2198126 SPACER 7 69
2198130 STEERING WHEEL 4 5 5 0
2198153 ROLLER, 3 97 26
2198153 ROLLER, 3 103 *
2198211 SWIVEL-CABLE CLAMP 7 53
2208036 SWITCH-PROXIMITY 61 56
2208036 SWITCH - PROXIMITY 83 17
2208049 MAGNET-ACTUATOR 61 55
2208049 MAGNET - ACTUATOR 83 18
2208058.07 HINGE-SEAT PLATE 11 2
2208079 BOTTLE-COOLANT 47 15
2208099 SWITCH - 90043 CH-14 83 19
2208139 CLAMP 47 39
2208139 CLAMP-TUBE 71 F116
2208139 CLAMP-TUBE 75 F116
2208139 CLAMP-TUBE 79 F116
2208174 OIL FILTER 5 1 2
2208174 OIL FILTER 7 1 2
2212043 BRACKET-OIL COOLER 47 12
2212045 GUSSET-RH 13 9
2212046 GUSSET-LH 13 8
2212049 BRACKET-VALVE MTG 29 4
2212064 COVER-ACCESS 11 10
2212072 SCREEN-HOOD 13 1
2212073 BRCKT-CASSAPA PUMP 5 10
2212073 BRCKT-CASSAPA PUMP 7 10
2212074 PLATE-FILTER BAFFLE 31 4
2212075 BRACKET-FILTER-HD 31 1
2212078 BAFFLE-FILTER HD 31 2
2212082 BACK-PLATE FENDER 11 9
2212087 COVER-ACCESS 33 8
2212087 COVER-ACCESS 35 19
2212092 BRACKET-RH VALVE MTG 29 5
2212094.6 MOTOR PLT-RH DECK 101 *
2212097.6 MOTOR PLT-LH DECK 101 4
2212098.6 MOTOR PLT-RH DECK 101 *
2212099.6 MOTOR PLT-LH DECK 101 *
2212109 BRACKET-SWITCH MTG 57 10
2212110 BRCKT-REAR ROLLER 61 57
2212116 BRACKET-STOP 61 69
2212118 BAFFLE-OIL COOLER LH 47 34
2212119 BAFFLE-OIL COOLER RH 47 35*
2212186.6 BRKT-72 HEIGHT ADJ (A) 97 40
2212187.6 BRKT-72 HEIGHT ADJ (B) 97 41
2212206 MOUNT-TOP MOTOR 7 79
2212230.7 BRACKET-SPRING 61 80
2213006 PIN-PIVOT 59 12
2213009 PIPE-MUFFLER 49 46
2213035 SPACER PUMP ARM 37 41
2213036 STOP HEIGHT ADJUSTMENT 97 9
2213040 SLEEVE-THREADED 25 37
2213041 STUD 25 18
2216003 WLDMT-LEVER SUPPORT 39 4
2216005 WLDMNT-LIFT LEVER 39 2
2216025 WLDMNT-CYL ROD PIN 57 5
2216037 WLDMT-TANK SUPPORT 59 38
2216041 WLDMNT-HOOK REAR RH 59 2 *
2216042 WLDMNT-HOOK REAR LH 59 1
2216071.6 WLDMT-SUPPORT ARM RH 97 29
2216072.6 WLDMT-SUPPORT ARM LH 97 11
2216077 WLDMT-REAR AXLE 25 13
2216084 WLMNT-BULKHEAD 11 6
2216096.7 WLDMT-LH SUB FRAME 61 50
2216097.7 WLDMT-RH SUB FRAME 61 49
2218000 HOOD-PLASTIC 13 2
2218002 VALVE-3 SPOOL LIFT 39 3
2218006 SCREEN 47 19
2218009 ISOLATOR-LF2-270 5 23
2218009 ISOLATOR-LF2-270 7 23
2218010 ISOLATOR-LR1-230 5 24
2218010 ISOLATOR-LR1-230 7 24
2218014 CYLINDER-LIFT 57 6
2218043 SEAL-FILTER BAFFLE 31 3
2218044 HOSE-RAD UPPER 47 17
2218045 HOSE-RAD LOWER 47 18
2218046 SENDER-FUEL LEVEL 3 3 6
2218046 SENDER-FUEL LEVEL 3 5 17
2218046 SENDER - FUEL LEVEL 83 10
2218069 RELAY-TIME DELAY 43 32
2218078 CAP-FUEL TANK 33 3
2218078 CAP-FUEL TANK 35 14
2218083 LANYARD 13 18
2218084 GROMMET 11 34
2218086 SEAL-TUBE 47 20
2218088 CABLE-BATTERY NEG. 7 55
