LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-105
* Not illustrated
2 001791171 Snap Ring, 1.187" 1
3 148070 Bearing-Ball 1-1/4 10 2
4 MBG5500 Spindle Housing 1
5 MBG5448A Extension 1
6 002993160 Lubricator-M6 X 90 Deg 1
7 143030 Spindle 1
8 143032 Spacer-Bearing 1
9 001791189 Snap Ring, 1.250" 1
10 143031 Spacer-Seal 1
11 148071-01 V-Ring V-60a 2
12 450944 Scrw-set M4 X 10, Cup Pnt 2
13 142108.7 Cap-Spindle 1
14 112243-03 Blade 1 (Use 112243-02 On 9'-8" Wing
Decks, Qty 4)
15 450393 Wshr-M16 X 30 X 3.3 1
16 001009770 Bolt-hex 5/8-18 X 7-3/4 1
17 64209-03 Spring Washer .67 Id 1
18 450020176 Nut-hex 5/8-18 1
19 450479 Scrw-hex M10 X 25 Verbus Ripp 4
33 SPINDLE ASSEMBLY
