LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-13
* Not illustrated
1 2212072 Screen-hood 1
2 2218000 Hood-plastic 1
3 MBG5364 Hinge-plate RH 1
3A 4128538 Hinge-plate LH 1
4 2212054A Hinge-adj Rh 1
5 2212051A Hinge-adj Lh 1
6 4125519 Wldmt-Fan Shroud 1
7 MBF1911 Radiator Support 1
7A MBF1912 Wldmt-Louvre Panel 1
8 2212046 Gusset-LH 1
9 2212045 Gusset-RH 1
10 4125219 Wldmt-RH Frame Rail 1
11 4125141 Wldmt-LH Frame Rail 1
12 450120267 Nut-hex 3/8-16 Nyloc 4
13 450378 Nut-hex M8 Nyloc 4
14 450241 Screw-hex M12 X 30 8
15 450392 Wshr-M12 X 24 X 2.7 12
16 452200029 Lockwshr-1/4 X .425 X .072 12
17 450168 Scrw-hex M6 X 12 14
18 2218083 Lanyard 2
19 450191 Scrw-hex M8 X 20 4
21 452200176 Lockwshr-1/2 X .873 X .125 8
22 450214 Scrw-hex M10 X 25 2
23 450391 Wshr-m10 X 21 X 2.2 4
24 450379 Nut-hex M10 Nyloc 2
25 113006-01 Bushing-.5x.32x.19 Lg 4
26 MBA5289A Wshr-8.5 X 25.5 X 3 4
27 450192 Scrw-hex M8 X 25 4
28 450239 Scrw-hex M12 X 20 3
29 450455 Nut-hex M12 Verbus Ripp 3
30 MBG2637 Handle-hood 1
31 4125539 Wldmt-Rear Axle Support 1
32 450048 Bolt-hex M12 X 40 4
33 450542 Scrw-pan Hd M6 X 20 8
34 450376 Nut-hex M5 Nyloc 4
35 W178142 Latch-rubber 2
36 450380 Nut-hex M12 Nyloc 7
37 2216033A Wldmnt-Bumper 1
38 64166-17 Blt-shldr 3/8-16x1.12 4
39 MAA0335A Wshr-17/32 X 25mm X 3/16 2
40 MBB6845A Toggle 2
41 009079280 Hook 2
42 64025-29 Nut-hex #8-32 Keps 8
43 001191140 Scrw-RND HD No.8-32 X 1/2 4
44 64002-02 Lckwshr-TH,Ext,#10 4
45 450190 Scrw-hex M8 X 16 8
46 64006-02 Lckwshr 5/16 8
5 FRAME - REAR
