LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-21
* Not illustrated
7A WHEEL MOTOR - FRONT
008007240 Wheel Motor 2
001 A808966 Seal kit 1
002 A808967 Seal kit 1
010 A808968 Cylinder-block Assy. 1
N/A • Piston sub-assy.CI.0
N/A • Piston sub-assy.CI.10
015 A808969 Repair kit. 1
025 A808970 Cam Assy. 1
027 N/A • O-ring. Part of seal kit 001 & 002
040 A808971 Valving cover assy. 1
041 N/A • Valving cover part.
042 N/A • Screw.
043 N/A • Seal washer. Part of seal kit 001 & 002
044 N/A • Screw.
045 N/A • O-ring. Part of seal kit 001 & 002
047 N/A • Valving.
048 N/A • Seal kit. Part of seal kit 002
050 N/A • Plug.
051 N/A • O-ring.
052 N/A • Spring.
053 N/A • Valve spool.
054 N/A • Washer.
055 N/A • Snap ring.
056 N/A • Spring.
057 N/A • O-ring. Part of seal kit 001 & 002
059 N/A • Pin.
065 A808972 Cover plate. 1
066 N/A • Screw.
067 N/A • Sealing ring.
070 A808973 Bearing support assy. 1
071 N/A • Bearing support.
072 N/A • Radial lip seal. Part of seal kit 001 & 002
073 N/A • Roller bearing.
074 N/A • Roller bearing.
075 N/A • Set of shims.
076 N/A • Thrust ring.
077 N/A • Snap ring
078 N/A • Lip Seal Part of seal kit 001 & 002
079 N/A • Deflector Part of seal kit 001 & 002
