LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-27
* Not illustrated
8A REAR WHEEL MOTOR
A W148141-03 Motor 1 ME15-02-08-AAAA
1 A800664 Special Bolts 7
2 End Cover 1
3 N/A Seal Ring-Commutator 1 contained in seal kit A820052
4 N/A Seal Ring 5 contained in seal kit A820052
5 Commutator 1
6 Commutator Ring 1
7 Manifold 1
8 A800826 Rotor Set 1
9 Wear Plate 1
10 A800825 Drive Link 1
11 Thrust Bearing 1
12 A800824 Coupling Shaft 1
13 Bearing/Bushing,Inner 1
14 Thrust Washer 1
15 Thrust Bearing 1
16 N/A Seal 1 contained in seal kit A820052
17 N/A Backup Washer 1 contained in seal kit A820052
18 Housing 1
19 Bearing/Bushing, Outer 1
20 N/A Dirt & Water Seal 1 contained in seal kit A820052
25 N/A Backup Washer 1 contained in seal kit A820052
B A820052 Seal Kit 1
To Next Page
