LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-33
* Not illustrated
1 2218154 Fuel-tank 1
2 2218148 Reservoir-hydraulic 1
3 2218078 Cap-fuel Tank 1
4 64152-05 10-32x1/2 R Mach Scr 5
5 64002-02 Lockwshr-tooth,Ext,#10 1
6 2218046 Sender-fuel Level 1
7 W148081 Gasket 1
8 2212087 Cover-access 1
9 450212 Scrw-hex M10 X 16 2
10 450412 Lockwshr-M10 X 15.9 X 2.5 8
11 450391 Wshr-M10 X 21 X 2.2 8
12 69051-01 Pipe Plug - 3/8 1
13 W148027 Breather Vent 1
14 2690017-01 Ftg-orb Plug 14 2
15 38471-08 Foam, Closed Cell 7.8'
16 09007-10 Hose .25x.8.5 1
17 2690017-03 Ftg-oab Plug 1
18 2212076b Support-hyd. Reservoir 1
19 008296050 Switch, Temp-175 F 1
20 450214 Scrw-hex M10 X 25 6
21 09007-10 Hose 1/4 X 10.5 1
22 88042n Hose Clamp 4
23 58026 3 Way Connctr 1/4 1
24 009151460 Gauge-oil Level 1
25 2218147 Grommet 1
26 2218162 Cap-rubber 25.4 1
27 108094-01 Clamp-hose Sae20 1
11 FLUID TANKS
To Next Page
