LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-37
* Not illustrated
1 W038404-02 Grip, Throttle Lever 1
2 MBF1971 Lever, Throttle 1
3 W118047-02 Bushing Flip-lok, 1/2 1
4 MBF1720 Clamping Collar 1
5 MBF1691 Collar 1
6 461901679 Sprg-disc 13 X 28 X 1 4
7 172088.07 Throttle Arm 1
8 450392 Wshr-m12 X 24 X 2.7 2
9 452436 Nut-hex M8 Flng Nyloc 1
10 450195 Scrw-hex M8 X 40 2
11 450324 Nut-hex M8 4
18 148057-06 Cable-throttle 1
20 128079 Rod End, 1/4 Female 1
39 MBG2938A Plate Pump 1
40 2720158 Spacer 6.35x15.88x9.52 1
41 2213035 Spacer Pump arm 1
42 64237-02 Locknut Nylon M6x1.00 1
43 64205.030 Blt Met M6x1.00x40 1
44 128089-02 Cable, CNTRL 36.50 LG 1
13 CONTROLS - THROTTLE / PUMP
