LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-47
* Not illustrated
1 450190 Scrw-Hex M8 x 16 8
2 64006-02 Lockwasher-Helical 5/16 16
3 4128624 Bracket - Batery 1
4 2178211 Radiator 1 (Use Service Cap 2178211-01)
5 452701 Scrw-Hex M8 x 16 Taptite 6
6 450389 Wshr-M6 x 12.5 x 1.8 10
7 450377 Nut-Hex M6 Nyloc 6
8 W64215-01 Rivet-Pop 3.2 x 8 6
9 48228-1A Clip-Cable Insulated 1
10 456110503 Scrw-Hex 1/4-20 x 5/8 1
11 450378 Nut-hex M8 Nyloc 3
12 2212043 Bracket-Oil Cooler 1
13 4123777 Shroud-Top Fan 1
13a* MBG7031 Brkt-Engine Cover 1
13b* 379050522 Beading 0.3 Mtr For 13a
13c* 450213 Scrw-Hex M10 X 20 2 For 13a To 13
13d* 450391 Wshr-M10 x 21 x 2.2 2 For 13c
13e* 450379 Nut-Hex M10 Nyloc 2 For 13c
14 006911730 Cooler-Hyd. Oil 1
15 2208079 Bottle-Coolant 1
16 4128625 Wldmt - Coolant Bottle Bracket 1
17 2218044 Hose-Rad Upper 1
18 2218045 Hose-Rad Lower 1
19 2218006 Screen 1
20 2218086 Seal-Tube 1
21 450191 Scrw-Hex M8 x 20 7
22 450390 Wshr-M8 x 17 x 1.8 13
23 450369 Nutsert-M8 A-l x 17.5 4 Use Insert Tool 2196247)
24 450213 Scrw-Hex M10 x 20 6
25 450391 Wshr-M10 x 21 x 2.2 11
26 450379 Nut-Hex M10 Nyloc 7
27 A904437 Foam 1
28 38471-08 Foam x 19.5 Lg 1
29 148034-07 Grommet-Insulation 1
30 48396 Clamp-Hose 2 Dia 4
31 450170 Scrw-Hex M6 x 16 6
32 38471-08 Foam 21.2 Lg 1
33 450214 Scrw-Hex M10 X 25 1
34 2212118 Baffle-Oil Cooler LH 1
35* 2212119 Baffle-Oil Cooler RH 1
36 MBA5289A Wshr-8.5 x 25.5 x 3 4
37 48450-07 Foam 1x28 1
38 450020 Bolt-hex M8 X 60 2
39 2208139 Clamp 2
40 MBF0365 Wshr-10.5 X 25.2 X 3 2
41 2690024-01 Plug 1/4 Npt 2
17 COOLING & EXHAUST
