LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-49
* Not illustrated
42* 4127198 Insulation-Exhaust 1
43 450453 Nut-hex M8 Verbus Ripp 2
44 4123047 Muffler 1
45 48378 Strap- Rubber 1
45 172212 Brkt-Upper Hanger 1
45 172290 Brkt-Lower Hanger 1
46 2213009 Pipe-Muffler 1
47 4122778 Wldmt-Exhaust Pipe 1
48 W048319-04 Clamp-Muffler 2-1/8 3
49 4122798 Pipe-Exhaust 1
50 - Gasket-ex. Manifold 1 (Perkins Number 135997030)
51 450411 Washer - Spring M8 4
52 450192 Scrw-Hex M8 x 4
53 A691139 Cap-Radiatator 1
54 450727 Screw - Cap Head M8 x 40 5
55 MBG5543 Battery Brace 2 Secures Battery
56 4128648 Bracket - Bug Screen LH 1
57 MBG7022 Fan Shroud Plate 1
17 COOLING & EXHAUST
To Next Page
