Page #189 background imageLoading...
Page #189 background image
LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-57
* Not illustrated
1 MBF1925.7 Wldmt-push Arm Lh 1
2 * MBF1926.7 Wldmt-push Arm Rh 1
3 46019A Pin Weld, Push Rod 2
4 452701 Scrw-hex M8 X 16 Taptite 2
5 2216025 Wldmnt-cyl Rod Pin 2
6 2218014 Cylinder-lift 2
(Use Seal Kit 002301110)
7 MBF1929 Wldmt-push Arm Pin 2
8 W038383 Switch-n.c. 1
9 W172359 Plate-push Arm Sw 1
10 2212109 Bracket-switch Mtg 1
11 001190042 Scrw-rnd Hd No10-24 X 1/2 4
12 001393298 Nut-hex No10-24 Nyloc 4
13 450191 Scrw-hex M8 X 20 2
14 450378 Nut-hex M8 Nyloc 2
15 001190377 Scrw-wlf 1/4-20 X 1/2 2
16 456110016 Scrw-hex 1/4-20 X 3/4 2
17 001399121 Nut-hex 1/4-20 Nyloc 2
18 001594080 Wshr-.516 X .750 X 12ga 8
19 W138024-02 Brg-dx,.500 I.d. 4
20 35027N Zerk 2
21 001594010 Wshr-.328 X .75 X 14 Ga 2
20 PUSHARM ASSEMBLY
