LIST OF PARTS
ITEM PART NO DESCRIPTION QTY REMARKS
960 FRONTLINE
PARTS MANUAL
Parts-97
* Not illustrated
1 MBF1932.6 Wldmt-Deck Cover 1
2 4540543 Screw - Recessed Pan head M6x25 4
3 * 001496036 Rivet-pop 4.85 X 19 4
3 2218152-02 Motor Hyd 14 1
* 2218152-04 S-Seal Kit A/R
4 453005165 Key-1/4 X 1/4 X 1-1/8 1
5 450382 Nut-hex M16 Nyloc 4
6 142064 Plate-Backing 2
7 450327 Nut-hex M16 2
8 64223-08 Sch Capscr M16x2.00x60 2
9 2213036 Stop Height Adjustment 2
10 450078 Blt-hex M16 X 100 2
11 2216072.6 Wldmt-Support Arm LH 1
12 W64189-7a Blt-hx Soc #10-32x1/2 3
13 453005165 Key-1/4 X 1/4 X 1-1/8 3
14 64239-01 Blt-”T”5/8-18x3 3/4 G8 2
15 450073 Blt-hex M16 X 70 2
16 001490226 ‘R’ Clip 2
17 148075-02 Bushing-ja 7/8 Bore 1
18 W148195 Pulley Ja 1
19 450191 Blt M8 X 20 4
20 W178121 Belt-Center Deck 1
21 Mbg6038 Pulley-5.75 Od 3
22 48450-16 Foam .5x4.0x.5 2
23 456110066 Scrw-hex 3/8-16 X 1 2
24 64188-40 1/2 X 2-5/8 Clevis Pin 2
25 46335 Shaft Asm-Roller 5
26 2198153 Roller, 3 7
27 W146067 Wldmt-Roller Shaft 1
28 Mbf1931a.6 Wldmt-Front Deck, Hr9510 1
29 2216071.6 Wldmt-Support Arm RH 1
30 450222 Scrw-hex M10 X 65 1
31 450325 Nut-hex M10 1
32 W172107.6 Plate-Motor 1
33 450391 Wshr-M10 X 21 X 2.2 4
34 450412 Lockwshr-M10 X 15.9 X 2.5 4
35 450215 Scrw-hex M10 X 30 4
* 450372 Nutsert-M10 A-l X 20.5 4
36 450454 Nut-hex M10 Verbus Ripp 3
37 452436 Nut-hex M8 Flng Nyloc 6
38 450457 Nut-hex M16 Verbus Ripp 2
39 452436 Nut-hex M8 Flng Nyloc 2
40 2212186.6 Brkt-72 Height Adj (A) 2
41 2212187.6 Brkt-72 Height Adj (B) 2
42* 009040250 Sealing Block 1
* 142088 Brkt-Roller 2 Rear Left For Item 25
* 002989470 Deck Cover Foam AR 2.8m Required.
30 FRONT CUTTING DECK
To Next Page
