NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM
PART NO DESCRIPTION PAGE ITEM
960 FRONTLINE
PARTS MANUAL
450020516 NUT-HEX 3/4-16 SLOTTED 25 22
450120055 NUT-HEX 1/2-13 25 25
450120055 NUT-HEX 1/2-13 43 3
450120233 NUT-HEX 1/2-13 NYLOC 61 43
450120267 NUT-HEX 3/8-16 NYLOC 13 12
450120267 NUT-HEX 3/8-16 NYLOC 45 49
451030201 BOLT-HEX 5/16-24 X 1-1/4 61 41
451030730 BOLT-HEX 1/2-20 X 3-1/2 59 34
451110346 BOLT-HEX 1/2-13 X 2-3/4 103 41
451110354 BOLT-HEX 1/2-13 X 3 25 20
451112681 BOLT-HEX 1/4-20 X 2 61 74
452000473 WSHR-9/16 X 1-1/8 X .104 5 6
452000473 WSHR-9/16 X 1-1/8 X .104 5 28 *
452000473 WSHR-9/16 X 1-1/8 X .104 7 6
452000473 WSHR-9/16 X 1-1/8 X .104 7 28 *
452100019 WSHR-1/4 X 5/8 X .064 59 28*
452100019 WSHR-1/4 X 5/8 X .064 61 72
452101510 WSHR-3/8 X 1-1/2 X .104 59 16
452200029 LOCKWSHR-1/4 X .425 X .072 7 36
452200029 LOCKWSHR-1/4 X .425 X .072 13 16
452200029 LOCKWSHR-1/4 X .425 X .072 61 78
452200134 LOCKWSHR-3/8 X .683 X .094 5 7
452200134 LOCKWSHR-3/8 X .683 X .094 7 7
452200134 LOCKWSHR-3/8 X .683 X .094 25 9
452200134 LOCKWSHR-3/8 X .683 X .094 31 11
452200134 LOCKWSHR-3/8 X .683 X .094 59 15
452200176 LOCKWSHR-1/2 X .873 X .125 11 35
452200176 LOCKWSHR-1/2 X .873 X .125 13 21
452200176 LOCKWSHR-1/2 X .873 X .125 25 24
452200176 LOCKWSHR-1/2 X .873 X .125 31 6
452200176 LOCKWSHR-1/2 X .873 X .125 61 52
452200176 LOCKWSHR-1/2 X .873 X .125 103 40
453005165 KEY-1/4 X 1/4 X 1-1/8 97 4
453005165 KEY-1/4 X 1/4 X 1-1/8 97 13
453005165 KEY-1/4 X 1/4 X 1-1/8 103 53
454000328 SPLIT PIN-1/8 X 1-3/4 25 23
455000387 PIN-TENSION 1/4 X 1-1/4 59 3
456110016 SCRW-HEX 1/4-20 X 3/4 57 16
456110016 SCRW-HEX 1/4-20 X 3/4 61 70
456110066 SCRW-HEX 3/8-16 X 1 31 12
456110066 SCRW-HEX 3/8-16 X 1 97 23
456110090 SCRW-HEX 1/2-13 X 1-1/4 31 8
456110448 SCRW-HEX 3/8-16 X 1-1/4 7 61
456110498 SCRW-HEX 1/4-20 X 1/2 11 33
456110503 SCRW-HEX 1/4-20 X 5/8 47 10
456110503 SCRW-HEX 1/4-20 X 5/8 59 19
456110503 SCRW-HEX 1/4-20 X 5/8 59 28
456110595 SCRW-HEX 3/8-16 X 3/4 25 8
456110595 SCRW-HEX 3/8-16 X 3/4 59 14
461901679 SPRG-DISC 13 X 28 X 1 37 6
461901679 SPRG-DISC 13 X 28 X 1 103 52
469009601 QUICK PIN 99 11
469009601 QUICK PIN 10 1 10
469016517 ‘P’ CLIP 73 F219
469016517 ‘P’ CLIP 77 F219
469016517 ‘P’ CLIP 81 F219
469020633 BRACKET-FOR FLASH 45 63
469021633 HOSE CLIP LARGE H98040773 F322
469021633 HOSE CLIP LARGE 77 F322
469021633 HOSE CLIP LARGE H98040781 F322
699535007 BALL JOINT 61 44
842000044 LUBRICATOR-1/4" STR 25 29
842000044 LUBRICATOR-1/4" STR 59 11
W148027 BREATHER VENT 71 F202
W148027 BREATHER VENT 75 F202
W148027 BREATHER VENT 79 F202
W158006-08 FTG-M/M 71 F104
W158006-08 FTG-M/M 75 F104
W158006-08 FTG-M/M 1 79 F104
W158006-11 FTG-M/M 1 ORS X 1-1/16 SAE 73 F324
W158006-11 FTG-M/M 1 ORS X 1-1/16 SAE 77 F324
W158006-11 FTG-M/M 1 ORS X 1-1/16 SAE 81 F324
W158007-01 90-M/M 11/16 ORS X 9/16 SAE 71 F1
W158007-01 90-M/M 11/16 ORS X 9/16 SAE 75 F1
W158007-01 90-M/M 11/16 ORS X 9/16 SAE 79 F1
W158007-05 90-M/M 1 ORS X 7/8 SAE 71 F7
W158007-05 90-M/M 1 ORS X 7/8 SAE 75 F7
W158007-05 90-M/M 1 ORS X 7/8 SAE 79 F7
W158007-06 90-M/M 1 ORS X 1-1/16 SAE 71 F107
W158007-06 90-M/M 1 ORS X 1-1/16 SAE 75 F107
W158007-06 90-M/M 1 ORS X 1-1/16 SAE 79 F107
W158007-09 90-M/M 11/16 ORS X 7/16 SAE 73 F206
W158007-09 90-M/M 11/16 ORS X 7/16 SAE 75 F206
W158007-09 90-M/M 11/16 ORS X 7/16 SAE 79 F206
W158061-09 O-RING .739 ID X .07 SECT 71 F113
W158061-09 O-RING .739 ID X .07 SECT 75 F113
W158061-09 O-RING .739 ID X .07 SECT 79 F113
001419072 ROLL PIN-3/16 X 7/8 45 40
001490226 ‘R’ CLIP 59 8
001490226 ‘R’ CLIP 97 1 6
001490226 ‘R’ CLIP 101 28
001496248 ROLL PIN-5/16 X 1 45 47
001594010 WSHR-.328 X .75 X 14 GA 7 34
001594010 WSHR-.328 X .75 X 14 GA 11 19
001594010 WSHR-.328 X .75 X 14 GA 15 50
001594010 WSHR-.328 X .75 X 14 GA 31 16
001594010 WSHR-.328 X .75 X 14 GA 57 21
001594080 WSHR-.516 X .750 X 12GA 15 49
001594080 WSHR-.516 X .750 X 12GA 39 11
001594080 WSHR-.516 X .750 X12GA 45 38
001594080 WSHR-.516 X .750 X 12GA 57 18
001594170 WASHER 59 10
001594170 SHIM 61 84*
001594200 LOCKWSHR-M14 X 24.1 X 3 5 28 *
001594200 LOCKWSHR-M14 X 24.1 X 3 7 28 *
001594200 SPRING WASHER M14 19 2
001599028 WASHER, 49/64" 25 40
001599052 WASHER 15 54
001791171 SNAP RING, 1.187" 105 2
001791189 SNAP RING, 1.250" 105 9
001925220 HOSE CLAMP, 8-22 7 67
001925220 HOSE CLAMP, 8-22 73 F317
001925220 HOSE CLAMP, 8-22 77 F317
001925220 HOSE CLAMP, 8-22 81 F317
001925570 HOSE CLAMP SIZE 28 9 *
001925700 HOSE CLAMP SIZE 36 9 *
001990357 CLAMP, 1.3/4" 9 9
002000643 LABEL - WING DECK WASH EC 93 2
002000643 LABEL - WING DECK WASH EC 93 2
002000643 LABEL - WING DECK WASH EC 95 2
002029050 THRUST BEARING 25 33
002039152 BRG-BALL 17 X 40 X 12 101 8
002090600 SERVICE KIT 103 *
002178211 RADIATOR 47 4
002178214 PUMP-4 SECTION GEAR 5 8
002178214 PUMP-4 SECTION GEAR 7 8
002178214 PUMP 4 SECTION 7 9 7 9
002188234 ROD-END 25 36
002190180 BUSH,1"X1.125"X0.75" 59 17 *
002190190 BUSH,1"X1.125"X1.25" 61 83
002190190 BUSH,1"X1.125"X1.25" 103 46
002190200 BUSH-FLNG 1.25"X1.50"X0.75" 99 2
002190200 BUSH-FLNG 1.25"X1.50"X0.75" 101 15
002444030 PLUG-7/16 SAE 73 F218
002444030 PLUG-7/16 SAE 77 F218
002444030 PLUG-7/16 SAE 81 F218
002449006 TEST POINT-1/4 BSPP 73 F333
002449006 TEST POINT-1/4 BSPP 77 F333
002449006 TEST POINT-1/4 BSPP 81 F333
002498400 TEE-M/F/M 11/16 ORS 73 F327
002498400 TEE-M/F/M 11/16 ORS 77 F327
002498400 TEE-M/F/M 11/16 ORS 81 F327
