NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM PART NO DESCRIPTION PAGE ITEM
960 FRONTLINE
PARTS MANUAL
148057-06 CABLE-THROTTLE 37 18
148071-01 V-RING V-60A 105 11
148075-02 BUSHING-JA 7/8 BORE 97 17
148075-02 BUSHING-JA 7/8 BORE 103 35
148090-03 HOSE-SUPPORT 5/8 73 F321
148090-03 HOSE-SUPPORT 5/8 77 F321
148090-03 HOSE-SUPPORT 5/8 81 F321
148090-03 CLAMP 61 65
148263-08 S HSE.56 X.31 X 16.0 7 46
148264-04 HOSE-FUEL 3/16" X 12" LG 7 66
158006-05 FITTING ORS/ORB 71 F2
158006-05 FITTING ORS/ORB 75 F2
158006-05 FITTING ORS/ORB 79 F2
158006-14 FITTING-ORB/ORS 73 F318
158006-14 FITTING-ORB/ORS 77 F318
158006-14 FITTING-ORB/ORS 81 F318
158006-15 FITTING-ORS/ORB 71 F204
158006-15 FITTING-ORS/ORB 75 F204
158006-15 FITTING-ORS/ORB 79 F204
158006-15 FITTING-ORS/ORB 35 3
158007-12 FITTING-90 ORS/ORB 71 F109
158007-12 FITTING-90 ORS/ORB 75 F109
158007-12 FITTING-90 ORS/ORB 79 F109
158007-14 FITTING-90 ORS/ORB 71 F9
158007-14 FITTING-90 ORS/ORB 75 F9
158007-14 FITTING-90 ORS/ORB 79 F9
158056- 02 FTG-ORS/O-RING TEE 73 F207
158056- 02 FTG-ORS/O-RING TEE 75 F207
158056- 02 FTG-ORS/O-RING TEE 79 F207
158058-16 FITTING-90 BARB ADJ 73 F307
158058-16 FITTING-90 BARB ADJ 77 F307
158058-16 FITTING-90 BARB ADJ 81 F307
158061-20 O-RING- 022 71 F114
158061-20 O-RING- 022 75 F114
158061-20 O-RING- 022 79 F114
158067-04 FTG-BLKHD ORS/ORS 71 F16
158067-04 FTG-BLKHD ORS/ORS 75 F16
158067-04 FTG-BLKHD ORS/ORS 79 F16
168142-03 STRIP-RUBBER 103 54
172042A.07 BRKT-STEERING 45 43
176147-01 WLDMT-HOOK FRNT LH 59 4
176147-02 WLDMT-HOOK FRNT RH 59 5 *
178043-7 FILTER TUBE 7 5 6 2
178088-01 FTG-ORS PLUG 1-14 73 F209
178088-01 FTG-ORS PLUG 1-14 77 F209
178088-01 FTG-ORS PLUG 1-14 81 F209
178092-22 LIGHT FOR ROCKER 87 17
178097-01 CLAMP-TUBE 73 F210
178097-01 CLAMP-TUBE 77 F210
178097-01 CLAMP-TUBE 81 F210
178097-01 CLAMP-TUBE 61 61
178102-01 SK10 2V B 67
178102-01 SK10 - 2V - T 67
178102-01 SK10 - 2V - T 67
178102-01 SK10 - 2V - T 67
178102-01 SK10 - 2V - T 69
178102-01 SK10 - 2V - T 69
178102-02 SK10 - 2V - B 69
178102-02 SK10 - 2V - B 69
178102-03 SK08 - 2V - T 69
178102-09 SEAL 67
178102-09 SEAL 69
178102-10 SEAL 67
178102-10 SEAL 69
178102-13 RV10 - 22H - 0 - V006 / 3.0 67 2
178102-14 PILOT PISTON 7013200S 67 4
178102-16 SV10 - 21W - 0 - V - 00 67 5
178102-16 SV10 - 21W - 0 - V - 00 69 5
178102-17 COIL 6351012 67 6
178102-17 COIL 6351012 69 6
178102-18 SAE PLUG 67 8
178102-18 SAE PLUG 69 9
178102-19 SAE PLUG 67 7
178102-19 SAE PLUG 69 8
178102-31 CV10 - 20 - O - V - 70 67 3
178102-34 RV10 - 2005H - (VITON) 69 4
178102-42 RV10 - 22H - 0 - V - 35 / M210 67 1
178102-57 PILOT PISTON 7013200S 69 7
178102-58 CV08 - 20 - 0 - V - 80 69 1
178102-59 CV10 - 20T - 0 - V - 300 69 2
178102-79 RV10 - 22H - 0 - V - 35 / 32 69 3
178154-01 BUSHING-CYLINDER 61 82
2178211-01 CAP-RADIATATOR 49 53
2211004A PLATE-MOTOR 25 34
2212051A HINGE-ADJ LH 13 5
2212054A HINGE-ADJ RH 13 4
2212076B SUPPORT-HYD. RESERVOIR 33 18
2212076BB SUPPORT-HYD. RESERVOIR 35 29
2212107A BRCKT-BATTERY HOLD DOWN 5 29
2212107A BRCKT-BATTERY HOLD DOWN 7 29
2216033A WLDMNT-BUMPER 13 37
2218014‘ LIFT RAM WING DECK 79 430.3
2218152-01 MOTOR 11CC 101 1
2218152-02 MOTOR HYD 14 97 3
2218152-04 S-SEAL KIT 97 *
2690017-01 FTG-ORB PLUG 14 73 F211
2690017-01 FTG-ORB PLUG 14 77 F211
2690017-01 FTG-ORB PLUG 14 81 F211
2690017-01 FTG-ORB PLUG 14 35 25
2690017-01 FTG-ORB PLUG 14 33 14
2690017-03 PLUG 73 F212
2690017-03 PLUG 77 F212
2690017-03 PLUG 81 F212
2690017-03 FTG-ORB PLUG -06 35 28
2690017-03 FTG-OAB PLUG 33 17
2690019-01 FITTING-ORS STR. STEM 71 F17
2690019-01 FITTING-ORS STR. STEM 75 F17
2690019-01 FITTING-ORS STR. STEM 79 F17
2690024-01 PLUG 1/4 NPT 47 41
2720158 SPACER 6.35X15.88X9.52 37 40
2720289 ASSY-M12 BOLT W/LANYARD 11 42
35027N ZERK 57 20
38404-01 GRIP,CNTRL LVR 59 6
38471-08 FOAM X 19.5 LG 47 28
38471-08 FOAM, CLOSED CELL 33 15
38471-08 FOAM 21.2 LG 47 32
38471-09 S-FOAM X 120 35 26
4128263-08 HOSE 9 11
43065A SPACER-BUSHING 103 51
46019A PIN WELD, PUSH ROD 57 3
48037A BOOT BATTERY TERM 7 39
48228-05 CLIP-CABLE,INSULATED 11 31
48228-06 CLAMP 45 71
48228-06 CLAMP 71 F25
48228-06 CLAMP 75 F25
48228-06 CLAMP 79 F25
48228-1A CLIP-CABLE INSULATED 47 9
48228-1A CLIP-CABLE INSULATED 73 F301
48228-1A CLIP-CABLE INSULATED 77 F301
48228-1A CLIP-CABLE INSULATED 81 F301
48228A CLIP-CABLE INSULATED 7 38
48450-07 FOAM 1X28 47 37
48450-16 FOAM .5X4.0X.5 97 22
48540-01 CLAMP-HOSE 7 71
48540-01 HOSE CLAMP WITTEK H 73 F310
48540-01 HOSE CLAMP WITTEK H 77 F310
48540-01 HOSE CLAMP WITTEK H 81 F310
58026-01 3 WAY CONNECTOR 3/8 71 F19
58026-01 3 WAY CONNECTOR 3/8 75 F19
58026-01 3 WAY CONNECTOR 3/8 79 F19
62464-4A WSHR,THRUST 1.25X1.9 25 11
64061-04 ROLL PIN-1/8X3/4 11 25
