Page 12
Laminar Light Pulse Control
NOTE This equipment may not be part of your system. Please check with your installer.
The LAMINAR PULSE CONTROL menu is used to set the pulse rate of the Laminar Jets.
NOTE Prior to operating this feature, the Laminar Pulse Control must be labeled to an auxiliary (for example, AUX 2). See "Using
System Setup - Label Aux Menu" to label the laminar pulse control to an auxiliary control.
To use Laminar Light Pulse Control
Highlight AUX 2 (or auxiliary assigned to laminar light) and press SELECT. The most recently selected pulse control
function will be displayed. Use the UP/DOWN arrow keys to highlight the desired selection and press SELECT.
NOTE If the BACK key is pressed when on this screen, then the most recently selected pulse control function will be selected
again. If the SELECT key or the BACK key is not pressed, and if it has been 15 seconds since the UP/DOWN keys have
been pressed, then the most recently selected LPC4 function will be selected again.
NOTE From the EQUIPMENT ON/OFF menu, you can turn the item ON or OFF or change the current setting. If you turn the
Laminar Pulser (LAMINAR PLSR) ON, you have the option to change the current setting or it will come on using that
setting.
Chiller
NOTE This equipment may not be part of your system. Please check with your installer.
The CHILLER selection controls the chilling operation of the heat pump. In order to use the chiller, the filter pump
must be turned on and the heat pump must be in CHILL MODE (see page 23, Using the System Setup Menu), and the
switch on the heat pump on the equipment pad must also be set to CHILL MODE.
NOTE CHILLER takes the place of EXTRA AUX or SOLAR HEAT. It is not possible to have any two of these on the
EQUIPMENT ON/OFF menu at the same time.
To use Chiller
Highlight CHILLER and press SELECT. Press the SELECT button to enable/disable the CHILLER. The CHILLER
uses the desired chilling temperature set point. Press SELECT to accept the value.
CHILLER
FILTER PUMP ON
SPA
POOL HEAT
SPA HEAT
CHILLER
AUX 1
AUX 2
AUX 3
AUX 4
AUX 5
AUX 6
AUX 7
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
FILTER PUMP ON
SPA
POOL HEAT
SPA HEAT
AUX 1
AUX 2
AUX 3
AUX 4
AUX 5
AUX 6
AUX 7
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ENA
NOTE The system will force the Chiller set point to always be at least 5 degrees Fahrenheit higher than the Heater set point.
Important Information on Chiller
You must manually change the setting at your heat pump from Heat to Chiller.
Important Information
Do not activate this feature unless you are certain that a Laminar Pulse Control (LPC4) is installed on your system
