Spa Side Switch Menu
The Spa Side Switch menu allows you to define which equipment is controlled by the buttons on the optional Spa
Side Switch(es). Default settings are spa, spa heat, Aux1 and Aux2.
You may want to write down your spa side switch button assignments so that you can label the buttons on the switch
with the label pack provided.
To set the Spa Side Switch
Highlight MENU/HELP and press SELECT, highlight SYSTEM SETUP and press SELECT, highlight SPA SWITCH
and press SELECT. Inside the SPA SWITCH menu, highlight the number of Spa Side Switches you have and press
SELECT. Use the UP/DOWN arrow keys to move the highlight bar to choose which button you are assigning, press
SELECT. Use the UP/DOWN arrow keys to move the highlight bar to choose which piece of equipment will be
associated with the button, press SELECT. After pressing SELECT on the piece of equipment, you will be returned
one screen to continue assigning Spa Side Switch buttons.
SYSTEM SETUP
SOLAR PRIORITY
ASSIGN JVAs
DIMMERS
COLOR WHEELS
SPA SWITCH
SPA LINK
SERVICE INFO
CLEAR MEMORY
MORE
SPA SWITCH
SETUP
1
2
3
Please select
the number of
SPA SWITCHES
you have.
SPA SWITCH
BUTTON SETUP
1
2
3
4
SPA
SPAHEAT
AUX1
AUX2
SPA SWITCH
BUTTON 1
FILTER PUMP
SPA
POOL HEAT
SPA HEAT
SOLAR HEAT
AUX1
AUX2
MORE
