Installation and Operation Manual
|
Jandy
®
Legacy™ Model LRZE Pool/Spa Heater by Zodiac
®

 

Improperinstallationormaintenancecancause
nauseaorasphyxiationfromcarbonmonoxide
inuegaseswhichcouldresultinsevereinjury,
ordeath.Forindoorinstallations,asanaddi-
tionalmeasureofsafety,ZodiacPoolSystems,
Inc.stronglyrecommendsinstallationofsuitable
CarbonMonoxidedetectorsinthevicinityofthis
applianceandinanyadjacentoccupiedspaces.

Uneinstallationouunentretieninadéquatpeut
causerlanauséeoul’asphyxieenraisondu
monoxydedecarboneprésentdanslesgazde
combustionetmêmeentraînerdesblessures
gravesoulamort.Pourlesinstallationsinté-
rieures,commemesuredesécuritéadditionnelle,
ZodiacPoolSystems,Inc.recommandefortement
l’installationdedétecteursdemonoxydede
carboneprèsdecetappareilainsiquedansles
espacesadjacentsoccupés.
Install the Legacy Model LRZ electronic heater,
vent caps and draft hoods in accordance with the
procedures in this manual, local codes and ordinances,
and in accordance with the latest edition of the
appropriate national code. See Section 1.4 "Codes and
Standards".
All gas-red products require correct installation
to assure safe operation. The requirements for pool
heaters include the following:
1. Field assembly (if required)
2. Appropriate site location (clearances) and
ooring
3. Sufcient combustion and ventilation air
4. Properly sized gas meter and piping
5. Proper electrical wiring (if required)
6. Adequate water ow
This manual provides the information needed to
meet these requirements. Review all application and
installation procedures completely before continuing
the installation.
 
The Legacy Model LRZ electronic heater is
shipped from the factory with the top assembly in
the low-prole conguration for outdoor installation.
The Legacy Model LRZ electronic heater is design
certied for indoor installation when equipped
with a draft hood, which must be installed without
modication.
The Legacy Model LRZ electronic heater is
also certied for installation in an outdoor shelter in
Canada when equipped with a draft hood. An outdoor
shelter is an enclosure not normally occupied which
does not communicate directly with occupied areas.
Check the rating plate on the heater or the Parts
List (Section 11) of this manual for the correct Jandy
draft hood or vent cap part number. See instructions
supplied with the draft hood or vent cap for installation
and attachment. When the draft hood is used, locate
the heater so as to be in the same atmospheric pressure
zone as the combustion air inlet to the heater.
 
 

Whenpoolequipmentislocatedbelowthepool
surface,aleakfromanycomponentcancause
largescalewaterlossorooding.ZodiacPool
Systems,Inc.,cannotberesponsibleforsuchwater
lossoroodingorresultingdamage.

Lorsquel’équipementd’unepiscineestsituésous
lasurfacedel’eau,unefuiteprovenantden’importe
quelélémentpeutcauseruneperted’eauimportante
ouuneinondation.ZodiacPoolSystems,Inc. n’est
pasresponsabledespertesd’eau,desinondations
oudesavariescauséesparuneinstallationouun
entretieninadéquat.
The Legacy Model LRZ electronic heater may
be installed indoors or outdoors as outlined in lat.er
sections. Location of the heater below or above the
pool water level affects operation of its water pressure
switch. See sections on water piping and heater
start-up for more information about this.
Avoid placing the heater in locations where it can
cause damage by water or condensate leakage. If this
is not possible, provide a suitable drain pan to catch
and divert any leakage. The pan must not restrict the
air ow around the heater.
All criteria given in the following sections
reect minimum clearances as stated in the national
standards. However, each installation must also be
evaluated, taking into account the prevailing local
conditions such as wind speed and direction, proximity
and height of walls that may block ventilation, and
proximity to public access areas.
 
The heater must be placed to provide clearances
on all sides for maintenance and inspection. There
must also be minimum distances maintained from
combustible surfaces, see Table 2.
At least 18" (457mm) access must be available in
front of the heater for burner removal and access to the
igniter.
