Technical data
General
Net weight (with attached connectors) approx. 358g
Packaging weight (including accessories) approx. 790g
Battery Lithium battery CR2032, 3V (approval i.a.w. UL 1642)
Service life of the backlight 40000h (after this period of time the background lighting effici-
ency will reduce by approx. 50 %)
Transport and storage
The following information applies for devices that are transported or stored in their original packaging.
Free fall 1m
Temperature K55 (-25 °C to +70 °C)
Relative humidity 0 to 90% RH
Ambient conditions during operation
The UMG 96RM-CBM/-P is intended for use in weather-protected, fixed locations.
Protection class II according to IEC 60563 (VDE 0106, part 1).
Rated temperature range K55 (-10°C .. +55°C)
Relative humidity 0 to 75 % RH
Operational altitude 0 .. 2000 m above sea level
Degree of pollution 2
Installation position vertical
Ventilation Forced ventilation is not required.
Foreign body and water protection
- Front
- Back
- Front with seal
IP40 according to EN60529
IP20 according to EN60529
IP42 according to EN60529
