janitza UMG 96RM-P - Connection Example

127
UMG 96RM-P/-CBM
Connection example
Digital outputs
UMG 96RM-P/CBM
Measuring voltage Measuring currrentAuxiliary voltage
RS485
16 17
B
A
B A
33 34 35
K3 K4
K5
K6
36 37
=
-
+
28 29 30 31 32
=
Digital inputs
13 14 15
24V
DC
K1 K2
=
-
+
+
-
DSub-9
Profibus
USB
PC
SPSSPS
(UMG 96RM-P)
V1
V2
V3
VN
3 4 5 6
1 2
N/- L/+
S2
S1
S2
S2
S1
S1
L1
L2
L3
Consumer
230V/400V 50Hz
N
S2 S1
I4
19 18
S2 S1 S2 S1 S2 S1 S2 S1
1)
UL / IEC approved overcurrent
protection system (6A type C)
2)
UL / IEC approved overcurrent
protection system (10A type C)
3)
Jumpers (external)
3) 3) 3)
2)1) 2) 2)
3)
