Recordings
2 recordings are preconfigured in the default factory
setting of the UMG 96RM-P and UMG 96RM-CBM.
Recordings are adjusted and extended via the software
“GridVis”.
• The smallest time base for records is 1 minute.
• A maximum of 4 recordings, each with 100 values are
possible.
Recording 1:
The following measured values are recorded with the
time base of 15 minutes:
• Voltage effective L1
• Voltage effective L2
• Voltage effective L3
• Current effective L1
• Current effective L2
• Current effective L3
• Current effective Sum L1-L3
• Active Power L1
• Active Power L2
• Active Power L3
• Active Power Sum L1-L3
• Apparent Power L1
• Apparent Power L2
• Apparent Power L3
• Apparent Power Sum L1-L3
• cos phi(math.) L1
• cos phi(math.) L2
• cos phi(math.) L3
• cos phi(math.) Sum L1-L3
• Reactive power fundamental L1
• Reactive power fundamental L2
• Reactive power fundamental L3
• Reactive power fundamental Sum L1-L3
The mean value, minimum value and maximum value
are also recorded for each measured value.
Recording 2:
The following measured values are recorded with the
time base of 1 hour:
• Active Energy Sum L1-L3
• Inductive Reactive Energy Sum L1-L3
