Measuring method
The UMG 96RM-P/-CBM measures uninterrupted and
calculates all root mean squares over a 10/12-period
interval. The UMG 96RM-P/-CBM measures the true
root mean square (TRMS) of the voltages and currents
applied to the measuring inputs.
Operating concept
There are several ways to program the UMG 96RM-P/
-CBM and retrieve measured values.
• Directly on the device using two buttons
• Via the programming software of the GridVis
• Through the device‘s homepage
• Via the RS485 interface with the Modbus protocol.
Data can be changed and retrieved with the help of the
Modbus address list (stored on the accompanying
data carrier).
These operating instructions only describe the operation
of the 96RM-P/-CBM using the 2 buttons.
The programming software of the GridVis has its own
“online help”.
Additional components that are not
included in the scope of deliverables will be
required for parameterisation via the RS485
interface.
