janitza UMG 96RM-P - Page 115

115
UMG 96RM-P/-CBM
19032 888 float RD VA Apparent power S L3
19034 890 float RD VA Sum; Ssum3=S1+S2+S3
19036 876 float RD var Fund. reactive power (mains frequ.) Q L1
19038 878 float RD var Fund. reactive power (mains frequ.) Q L2
19040 880 float RD var Fund. reactive power (mains frequ.) Q L3
19042 882 float RD var Sum; Qsum3=Q1+Q2+Q3
19044 820 float RD - Fund.power factor, CosPhi; U L1-N IL1
19046 822 float RD - Fund.power factor, CosPhi; U L2-N IL2
19048 824 float RD - Fund.power factor, CosPhi; U L3-N IL3
19050 800 float RD Hz Measured frequency
19052 - float RD - Rotation field; 1=right, 0=none, -1=left
19054 - float RD Wh Real energy L1
19056 - float RD Wh Real energy L2
19058 - float RD Wh Real energy L3
19060 - float RD Wh Real energy L1..L3
19062 - float RD Wh Real energy L1, consumed
19064 - float RD Wh Real energy L2, consumed
19066 - float RD Wh Real energy L3, consumed
19068 - float RD Wh Real energy L1..L3, consumed, rate 1
19070 - float RD Wh Real energy L1, delivered
19072 - float RD Wh Real energy L2, delivered
19074 - float RD Wh Real energy L3, delivered
19076 - float RD Wh Real energy L1..L3, delivered
19078 - float RD VAh Apparent energy L1
19080 - float RD VAh Apparent energy L2
19082 - float RD VAh Apparent energy L3
19084 - float RD VAh Apparent energy L1..L3
19086 - float RD varh Reaktive energy L1
19088 - float RD varh Reaktive energy L2
19090 - float RD varh Reaktive energy L3
19092 - float RD varh Reaktive energy L1..L3
Modbus Address
Address Above display Format RD/WR Unit Note
