C
When using the digital outputs as pulse
outputs the auxiliary voltage (DC) must
have a max. residual ripple of 5%.
C
Functions for the digital outputs can be
adjusted clearly in the GridVis software
provided in the scope of deliverables. A
connection between the UMG 96RM-P/
-CBM and the PC via an interface is re-
quired for the use of the GridVis software.
These outputs are electrically isolated from the evaluation
electronics by optocouplers. The digital outputs have a
common reference.
• The digital outputs can switch DC and AC loads.
• The digital outputs are not short circuit protected.
• Connected cables longer than 30 m must be shielded.
• An external auxiliary voltage is required.
• The digital outputs can be used as pulse outputs.
• The digital outputs can be controlled via the Modbus.
• The digital outputs can output results from
comparators.
