janitza UMG 96RM-P - Page 83

83
UMG 96RM-P/-CBM
Profibus profile number 10
Byte
index
Value type Value
format
Scaling
1 1 Effective power L1 Float 1
2 5 Effective power L2 Float 1
3 9 Effective power L3 Float 1
4 13 Effective power sum L1..L3 Float 1
5 17 Effective current L1 Float 1
6 21 Effective current L2 Float 1
7 25 Effective current L3 Float 1
8 29 Effective current L4 Float 1
9 33 Effective current sum L1..L3 Float 1
10 37 Effective energy sum L1..L3 Float 1
11 41 Cos phi (math.) L1 Float 1
12 45 Cos phi (math.) L2 Float 1
13 49 Cos phi (math.) L3 Float 1
14 53 Cos phi (math.) sum L1..L3 Float 1
15 57 Reactive power fundamental oscillation
harmonic L1
Float 1
16 61 Reactive power fundamental oscillation
harmonic L2
Float 1
17 65 Reactive power fundamental oscillation
harmonic L3
Float 1
18 69 Reactive power fundamental oscillation
harmonic sum L1..L3
Float 1
19 73 Apparent power L1 Float 1
20 77 Apparent power L2 Float 1
21 81 Apparent power L3 Float 1
22 85 Apparent power sum L1..L3 Float 1
Profibus profile number 11
Byte
index
Value type Value format Scaling
1 1 Effective voltage L1 Float 1
2 5 Effective voltage L2 Float 1
3 9 Effective voltage L3 Float 1
4 13 Effective current L1 Float 1
5 17 Effective current L2 Float 1
6 21 Effective current L3 Float 1
7 25 Effective current L4 Float 1
8 29 Effective power L1 Float 1
9 33 Effective power L2 Float 1
10 37 Effective power L3 Float 1
11 41 Effective power sum L1..L3 Float 1
12 45 Counter status digital input 1 Integer (4 Byte) 1
13 49 Counter status digital input 2 Integer (4 Byte) 1
14 53 Counter status digital input 3 Integer (4 Byte) 1
15 57 Counter status digital input 4 Integer (4 Byte) 1
16 61 Status digital output 1 Integer (2 Byte) 1
17 63 Status digital output 2 Integer (2 Byte) 1
18 65 Status digital output 3 Integer (2 Byte) 1
19 67 Status digital output 4 Integer (2 Byte) 1
20 69 Status digital output 5 Integer (2 Byte) 1
21 71 Status digital output 6 Integer (2 Byte) 1
C
Measured values in integer format do not re-
spect the transformer ratio. Measured values
in floating point format contain the transfor-
mer ratio: value in the UMG 96RM-P display =
transformer ratio x value PLC x solution
