SEWING MACHINE MODEL DC5100
FRONT COVER
TO REMOVE:
1. REMOVE THE TOP COVER, BELT COVER AND BED COVER.
2. LOOSEN THE SETSCREWS (A), (D), (E) AND REMOVE THE SETCREWS (B), (C) AND (F).
3. REMOVE THE FRONT COVER.
TO ATTACH:
4. FOLLOW THE PROCEDURE ABOVE IN REVERSE.
SETSCREW (A)
SETSCREW (B)
SETSCREW (C)
SETSCREW (D)
SETSCREW (E)
SETSCREW (F)
SERVICE ACCESS (4)
HOOK
