37
SEWING MACHINE MODEL DC5100
TO REMOVE:
1. REMOVE THE FRONT AND REAR COVER (SEE PAGE 16).
2. REMOVE THE TWO SETSCREWS AND REMOVE THE MACHINE SOCKET.
TO INSTALL:
3. TO INSTALL THE MACHINE SOCKET, FOLLOW THE ABOVE PROCEDURE IN REVERSE.
NOTE:
PULL OUT THE CORD IN FRONT OF THE ARM TO PREVENT IT FROM CONTACTING
WITH THE LOWER SHAFT OR OTHER MOVING PARTS, AND SECURE IT TO THE FEED
MOTOR CORD WITH A BINDER.
SETSCREW
MACHINE
SOCKET
REPLACING MACHINE SOCKET (UNIT)
SETSCREW
