151
The water heater is running in energy saving mode. Propane gas is
used to prevent freezing. The temperature in the water heater is automatically kept
above 41°F (5°C). Water temperature coming out of the xtures is approximately
120°F (49°C). When the water heater is running in ECO MODE, a yellow LED
(3) will be lit in the middle of the rotary dial control switch inside the RV.
The appliance is running in a mode that provides rapid
availability of hot water. Water temperature at the xtures is 120°F (49°C)
System is operating in Stand By Heat, which keeps water temperature in the ap-
pliance at 102°F (39°C). While running in COMFORT MODE the yellow status
LED (3) on the rotary dial will be lit.
When the power switch is OFF, the appliance is not running in any operating
mode. Yellow status LED (3) on the rotary dial is lit.
: ( Prevention of freezing using
12VDC electricity. If the accessory electric antifreeze kit is installed, and the
appliance switched ON, the temperature in the water heater is automatically held
above 41°F (5°C). During operation the yellow status LED (3) is lit.
: (Decalcication) This mode is only available on the Aqua Go COM-
FORT or COMFORT PLUS models. For safety reasons after 30 seconds the de-
calcication process cannot be stopped until the system has been rinsed. (Refer to
Decalcication and Rinsing the System)
Valve is not serviceable; if defective it must be replaced.
Tampering with the valve will result in scalding injury. Do not place a
plug or reducing coupling on the outlet part of the valve. If you use a
discharge line allow complete drainage for both valve and line.
Tampering with the valve will void the warranty.
