39
The fth wheel factory installed pin box is not interchangeable. Maintain the proper pin box
weight on the hitch.
There is no recommended hitch height for fth wheels; usually the fth wheel pin box is
adjustable for variance in trucks and truck suspension systems.
Adjust the hitch assembly so the tow vehicle and the fth wheel are essentially level. A high
hitch will transfer weight behind the axles and cause the vehicle to shtail.
A low hitch will transfer additional weight to the hitch. Refer to the hitch manufacturer
instructions to adjust the weight distributing hitch to the proper height.
If you have additional questions, consult with your dealer. Make certain your Dealer is
aware of the tow vehicle you are using so a compatible hookup is achieved.
The following procedure will help to assist you in securely hooking up your recreation ve-
hicle to your tow vehicle.
1. Make sure the trailer wheels are blocked.
2. Make sure the hitch lever is in its open or “cocked” position unless it has been designed
to open automatically. Adjust the fth-wheel travel trailer pin to the proper height.
Lower the tailgate, if applicable.
3. Back the truck so the hitch encircles the fth-wheel/travel trailer pin.
4. A gentle contact of the hitch saddle against the pin will cause the mechanism to close.
5. Secure the hitch lever as specied by the manufacturer.
6. Put the truck in drive (DO NOT press on the accelerator) and ‘bump’ the hitch to make
sure it is locked.
7. Be sure to raise the fth-wheel landing gear all the way up.
8. Attach the breakaway switch cable to the tow vehicle.
9. Plug the wire harness/connector plug from the tow vehicle to the fth wheel.
10. Remove the wheel chocks from the trailer wheels.
can be operated manually. The fth wheel landing gear must be
fully retracted before moving or towing the RV to prevent damage.
The fth wheel landing gear is designed
to bear the front loaded weight of the RV only.
Wire Harness/Connector Plug
A 7-way wire harness/connector plug is wired into your trailer to connect electrical power
from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance
lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in
both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
When attaching wires to your tow vehicle, tape all the connections for moisture protection.
