190
Hang from, or hang more than 20 pounds from the cross-connecting shaft.
Allow anyone to ride or occupy the bed(s) while the RV is in motion.
Exercise care when loading cargo/vehicles in the cargo area to avoid damage to
the bed mechanism.
Secure loads properly in the cargo area to avoid damage to the bed mechanism
from shifting or falling loads.
When the sofa seats are unfolded into the at (bed) position,
they must be locked so they can’t be opened into the seated
position. The lock mechanism is shown above. There is a
separate lock for each seat. The lever at the left side of the
lock must be pushed in towards the label, which will lock the
seat in the at position. To release it so it can be unfolded
into the seated positon, pull the lever away from the label
before ipping the seats. The arrow in the photos is pointing
to the loop used to pull the lever. This lever slides toward the
label and away from the label.
The electric bed lift operates on 12-volt DC power supplied
by the tow vehicle charge line, auxiliary batteries, or power
converter. The recreation vehicle should be hooked up to
120-volt AC power and have the power converter operat-
ing, if possible.
There are two separate switches used to operate the bed lift;
a red lighted master shuto switch and the bed lift
up/down switch . Both are typically located in the
command center panel.
In some models, the master switch is still on the command
center panel but the bed-lift control switch may be located
The powered sofa seat/beds in the cargo bay MUST be folded at into the
sleeping position before raising them up under the upper bed for loading
the cargo bay. DO NOT operate the bed lift when seats are opened in the
seating position.
Seats should be locked in the at (bed) position using the sofa lock mech-
anism.
