Winegard Air 360 Plus System (If So Equipped)
The Winegard Air 360 Plus system is a xed omnidi-
rectional TV/FM antenna, plus Wi-Fi, and 4G extender.
The antenna enclosure is 8 inches high and 17 inches in
diameter. Antennas are powered by +12VDC supplied
with a cable attached to the enclosure.
Inside the roof antenna enclosure are 3 types of anten-
nas.
• An antenna to receive FM radio and OTA (Over-
The-Air) VHF/UHF HDTV signals.
• An antenna to pick up any Wi-Fi signals being
broadcast in the area.
• An 4G/LTE antenna to receive a 4G/LTE signal from your wireless cellular provider.
Certain luxury fth wheels will have the ceiling
mounted router box as a standard item. (Fig
1). It is installed on the ceiling of the bedroom
positioned directly beneath the roof-mounted
Winegard Air 360+ antenna. Connections from
the antenna to the router box are pre-wired at
the factory.
Certain other RV models have this router box as
an optional item, which can be installed by the
dealer. The connections for the box (from the
antenna) are prepped from the factory and the
wiring is located behind the white cap on the ceiling shown
in .
The router box requires +12VDC power to operate, and is
controlled with a switch located on the bedroom ceiling next
to the router box. .
This router box, can receive a cellular data connection
To receive 4G/LTE signal you must have a subscription to a 4G/
LTE service. Connecting to the internet through a 4G/LTE connection will
use data from your service provider.
Wi-Fi signals picked up by the antenna may be password pro-
tected. If you do not know the password you won’t be able to log in to them.
