2.4.2 Delete one DMX address
Enter config menu by pressing softkey CONFIG.
Select PATCH menu by pressing softkey.
To delete one DMX address move cursor by turning the encoder wheel located in the middle.
Press softkey OPEN to confirm process.
2.4.3 Delete all DMX addresses
Enter config menu by pressing softkey CONFIG.
Select PATCH menu by pressing softkey.
To delete all DMX addresses press softkey CLEAR and the
corresponding softkey either for:
ALL: all DMX addresses
SCAN: only fixtures DMX.addresses
AUX: only AUX-key DMX addresses
PAR: only dimmer channels DMX addresses
2.4.4 Enter dimming curve
Dimmer/Par and aux channels can work in different modes (linear, exoponetioa and switch)
The assignment is made in the patch menu.
Enter config menu by pressing softkey CONFIG.
Select PATCH menu by pressing softkey.
Select from:
linear mode
exponential mode
switch mode
Press softkey CURVE to select the desired mode.
à to leave menu press ESCAPE
