5. Operation and maintenance devices
5.7.5. Service-Center (optional)
Attention!
Do not clean the Service-Center with a high pressure washer. Danger of damaging the
electric system and water getting into the fuel tank.
The Service-Center contains the following components:
motor Control-Panel
fuel tank and fuel gauge
Toolbox incl. Tools
overload safety device (optional)
battery
Service-Center, schematic display, differences in design and type possible.
For maintenance and cleaning the Service-Center is – depending on the model - swivel
mounted. To swivel it follow these points:
- Open the eccentric lock (between engine and Service-Center).
- Swivel the Service-Center.
- After finishing the maintenance or cleaning work, swivel back the Service-
Center.
- Close the eccentric lock.
