BATT or FUEL LOW: The valve will pulse in any of these conditions
FAIL- SAVE: The valve will pulse if the ECU detect a fail safe
BATT,FUEL,FAILS: The valve will pulse in any of these conditions
ENABLESmokePmp: Enables signal for smoke pump only if engine is running.
The pump can’t run without a running engine
(only useful by operate a JetCat Smoke pump)
High-Temp. The valve will be pulse in case of excessive exhaust
temperature.
MaxRPM-reached: The valve will be pulsed if the engine has reached its
maximum RPM.
Disabled: No function, off.
Note:
The smoke warn function is switched off while the throttle stick is in idle position.
Operation mode See page: 28, Operation modes
THR-Ctrl Input The following options are available:
ServoPWM direct: Engine control via Servo PWM Signal
AirSpeed Signa
l
: Engine control via analogue Signal on “AirSpeed” input
IdleThrResponse Adjustment of the throttle response (acceleration) by idle (up to average speed)
Fast default setting
Normal average acceleration
Slow slow acceleration for excessive warm weather or for operate
more than
1000m
sea level
FullThr Response Adjustment of the throttle response by full throttle (from average speed to full)
Fast default setting
Normal
normal
acceleration (for operation above 1000m)
AutoRestart In case the engine would flame out during normal run, the system can be programmed
to automatically try a restart of the engine and resume operation. Per default the Auto
restart feature is disabled for safety reasons.
A restart always can be interrupted via the normal controls which stop the engine.
The following options are selectable:
Disabled (Default, recommended)
Enabled (engine will be restarted in case of flame out)
ThrottleMax (engine will be restarted instantly, but operator must bring throttle stick to
full throttle position within 6 seconds (after the flameout happened) in order not to
interrupt/stop the restart attempt.
AirSpeed units Displayed flight speed unit in km/h or mph
