Instruction
m
anual JetCat
-
PRO engines
,
1.7
-
V12.01V
LIN-SpeedCtrl
3-StepSpdCtrl
Hold-Speed
SwitchSpeedLim
FailSafe delay Delay in seconds before Fail-Safe function will be activated.
While this time the engine speed run on the last valid stick pulse (→HOLD) adjustable
range = 0.1 -20.0 seconds.
After expiration of this term the Fail-Safe Time Out starts. (see next point)
FailSafeTimeOut Delay in front of Fail Save cut off.
While this time the engine speed is set to the Fail Save RPM (next point)
Is there no valid pulse after the expiration of this term the engine will be cut off by the
ECU. Range 0.1-20 seconds.
FailSafeRPM Programmable engine speed for the Fail-Safe Time Out procedure.
Range from minim
um RPM to maximum RPM.
AUX-ch SmokeCtrl To be able to use this function its necessary that the AUX-channel func is activated by
ON,TrbCtrl Off (see above).
This option defines the smoke pump control option for the 3-step switch.
The ECU can directly control a smoke valve or a Smoke pump for injection of smoke fluid
into the exhaust blast to generate smoke.
You can use the shut off valve (Part# 61106-00) as smoke valve. For smoke pump, you
can use any Jetcat Smoker pump
AUX-channel programming for smoke function ( 3-step switch)
Settings:
DISABLED
Smoke solenoid is not used → valve is constantly closed
Open if AuxSw=0
Smoker-valve is open if:
Turbine is running and the AUX switch (3-Pos. switch) is brought to lower position (“off”
position)
That is to say the Aux switch is enabled for smoke function but not for engine control.
Open if AuxSw=2
Smoker -valve is open if:
Turbine is running and the Aux switch (3-Pos.switch) is brought to upper position
(“AUTO-OFF” position)
To be able to use this function its necessary, that the AUX-channel func is activated by
ON,TrbCtrl Off (see above).
The
Aux switch is enabled for smoke function but not for
engine
control.
Smoker WarnFunct If this function is activated, the smoke-valve will pulse in a sequence of 0,2 secs on and
0,4 sec off –time if following conditions are complete:
BATTERY LOW: The valve will pulse if the ECU battery is weak/empty.
FUEL LOW: The valve will pulse if the fuel level is low the programmed
LowFuel Limit
