20
4. VIEW OF MOTORIZED SURF
4 VIEW OF MOTORIZED SURF
4.1. DESCRIPTION OF JETSURF ELECTRIC
Pad
Strap
Cover of motor com-
partment
Battery Pack locks
Handle
Cover of motor com-
partment
B
A
Cooling water outlet
B
Cover of the ventilation
system
Indicator ECU
p.25
A
JE_0402
JE_0403
JE_0401
