56
11. MAINTENANCE PERFORMED BY THE USER
11. MAINTENANCE PERFORMED BY THE USER
11.1. BALANCING VALVE REPLACEMENT
• Remove 4 (four) socket head screws on the
motor cover.
4 x screw M6x12
Tightening torque 3,5 N.m
Caution (Risk of Injury)
Before checking the motor compartment, always remove the battery from your JetSurf
Electric. You will thus avoid a possible electrical injury. (
p. 27)
• Remove the cover of the ventilation system
A
by turning it anticlockwise.
• Remove the balancing valve
B
, with your
hand by turning it anticlockwise.
• Fit a new valve and gently screw it in clockwise with your hand until the O-ring touches
the sealing seat.
• From this moment, tighten the valve with your hand by 180°.
A
OPEN
CLOSE
B
JE_814
JE_816
JE_1002
