5. CONTROLS
5.2. INDICATOR
Jetsurf Electric is equipped with an indicator that indicates all the states of the motorized surf,
the signaling of which is necessary for the safe operation of this motorized surf.
Indicator
A
has these functions :
SIGNALLING:
• signalling the Battery Pack condition
• signalling the conditions and errors of the ECU
CONTROLLING:
• By placing the key on the indicator, you will
switch o the ECU
5.2.1. TABLE OF SIGNALIZATIONS
INDICATION COLOR SIGNALIZED CONDITION
Flashing red Too much pressed throttle trigger during the start.
Lights purple Diagnostics is ok.
5.2.2. SIGNALIZATION OF BATTERY CONDITION
The Battery Pack conditions are indicated by indicator color lighting.
INDICATION COLOR BATTERY CONDITION
Green 100-75% capacity
Blue 75-50% capacity
Orange 50-25% capacity
Red Under 25% capacity
5.2.3. SAFE RETURN MODE
When signalization light turns red, there is about 2 (two) minutes of riding remaining time
before the motorized surf turns to Safe Return Mode. Safe Return Mode decreases the
motorized surf power for safe return back to the shore. In Safe Return Mode, it is possible to
make up to 400m distance (depends on weather and water surface conditions).
A
JE_0503
