P22 P23
P24
P25
P26
P27 P28
P29 P30
P21a
P21a Gauge arm for rim width.
P22 Display of unbalance measured and direction
indicator (red arrows or arrow heads)
P23 Correction position reached (green arrows)
P24 Correction position for both correction planes
reached
P25 Compensation run carried out
P26 Start measuring run by pressing the START key
after closing the wheel guard.
P27 Calibration weight
P28 Main shaft
P29 Select memory location for wheel profile (red
arrow)
P30 Select a previously stored wheel profile (green
arrow)
70g 0g
