5.9 EEP CODES
The beeps codes are made to recognize the malfunction of the machine in case of display problem.
5.9.1 ABBREVIATIONS
Beeps
*
Frequency : 2000 Hz
Duration : 100 ms
Pause : 100 ms (Pause after beep, total length = 200 ms)
S
Frequency : 1600 Hz
Duration : 200 ms
Pause : 400 ms
L
Frequency : 1600 Hz
Duration : 500 ms
Pause : 400 ms
nS or nL
n repeats of S or L
Pause
Pn
Duration : n seconds
5.9.2 BEEP SEQUENCES
A beep sequence consists of a
Ø - A - : Prefi x beep
Ø - B - : Beeps which indicates the initialisation step
Ø - C - : Beeps which indicates the module/object
Ø - D - : Pause between the cycle
5.9.3 –A- PREFIX BEEP
Each beep will be indicated by a prefi x beep
Ø P0.5
5.9.4 -B- BEEPS OF THE INITIALISATION STEP
Beep sequence Description ID MODULE
S P1
Error during basic initialisation:
I2C bus (Keyboard, keyboard cable) 22
Message server 83
Command language 81
S S P1
Error during PO (persistent objects) based initialisation:
Encoder board of main shaft 29
External AD converter 25
Internal AD converter 26
Temperature sensor measurement 27
Data conditioning 42
S S S P1
Extensions, based on Pos:
Keyboard/display, SAPE, brake, motor 44, 45, 46, 47, 48
Drive system 49
