JohnBean B9800 - Saving Settings for Models of Operation and Calibration Data; User C Codes Reference

63
C Description
104 Test the RC time constant of the unbalance transducers
111
110 Indication of the operating voltages supplied by the power supply module.
115 Calibration of the unbalance measurement with test rotor only
6.3 ENTERING SERVICE C CODES AND OPTIONS
Ø C code: The service menu is accessed by holding down the C CODE and WEIGHT PLACMENT keys.
The user c-code menu is accessed by pressing the F-key and afterwards the c-code key.
Ø Note: The service menu is for service personnel only. Not for customers. The last service code used
since power on is displayed.
Ø Options: Press +/- keys To choose an option of a C code.
Ø Acknowledge: Press "FINE" key to acknowledge the option chosen.
Ø Abort: The service menu can be exited by pressing the "STOP".
Ø Special function: Press the Optimisation key to activate the special function.
Ø Measuring run: Indicator not available.
6.4 SAVING SETTINGS FOR MODES OF OPERATION AND CALIBRATION DATA
C10 : Save modes of operation (user settings)
C90 : save calibration data
SYSTEM RESET: The balancer is always reset after C47, C85, C86 have been carried out.
6.5 USER C CODES REFERENCE
C0 Load con! guration from default pro! le
Options:
0 : No action
1 : Set default values
Special function: None
Description: Pressing the Acknowledgment key resets the user settings to values defi ned under factory setting
profi le (default values). The chosen mode of operation can be transferred to the permanent memory
The following modes of operation are activated simultaneously by pressing the Acknowledgment key.
FUNCTION STATUS / VALUE CODE
Unbalance display Dynamic
Wheel Dimansion
distance = 115mm (SAPE)
diameter = 15"
width = 6,5"
Wheel type Car in inches Type 1
Weight placement Normal
Resolution of unbalance readings Low 0 C1
Suppression of minor unbalance readings (
On 1 C2
Measurement units of the unbalance readings Grams / Ounces 0 / 1 C3
Compensation of adaptor unbalance Off 0 C4
Number of revolutions for measurement
5-25 10 C6
Threshold for unbalance suppression in grams/
ounces
3.5 -20 g
0.12 - 0.71 oz
C8
Position brake after measuring run
On 1 C11
Starting measurement run by closing the wheel guard
On 1 C13
Comments: None
