68
C21 Indication of the program version & model number
Options: Indication of model designation
Special function: None
Description: Indication of program version number.
Press Option key to read out the model designation.
Comments:None
C28 Display & clear error record
Options:
0 : Do not clear the error memory
1 : Clear the error memory.
Special function: none
Description: The last 10 di! erent malfunction codes are written into the error memory so that they can be called
up and reported by the operator of the wheel balancer e.g. for remote diagnosis of malfunctions. The most recent
malfunction code is written into memory location 1 and the previous error codes are shifted to the higher memory
locations.
6.6 SERVICE C CODES REFERENCE
C0 Load con! guration from default pro! le
Options:
0 : No action
1 : Set default values
Special function: None
Description: Pressing the Acknowledgment key resets the user settings to values de" ned under factory setting
pro" le (default values). The chosen mode of operation can be transferred to the permanent memory
The following modes of operation are activated simultaneously by pressing the Acknowledgment key.
FUNCTION STATUS / VALUE CODE
Unbalance display Dynamic
Wheel Dimansion
distance = 115mm (SAPE)
diameter = 15#
width = 6,5#
Wheel type Car in inches Type 1
Weight placement Normal
Resolution of unbalance readings Low 0 C1
Suppression of minor unbalance readings (
On 1 C2
Measurement units of the unbalance readings Grams / Ounces 0 / 1 C3
Compensation of adaptor unbalance O! 0 C4
Number of revolutions for measurement
5-25 10 C6
Threshold for unbalance suppression in grams/
ounces
3.5 -20 g
0.12 - 0.71 oz
C8
Position brake after measuring run
On 1 C11
Starting measurement run by closing the wheel guard
On 1 C13
Comments: None
