73
C63 Continuous measurements - balancers with digital display
Options:
Press “+/-” key to switch from step to step.
Press “-”key for:
1. Amount of unbalance of both correction planes
2. Amount of unbalance plus angular location in degrees for left-hand correction plane
3. Amount of unbalance plus angular location in degrees for right-hand correction plane.
(The relative correction plane is signalled through the direction indicator).
Special function:
1. Number of measurements carried out during the test with code C63.
2. The mean of unbalance plus angular location in degrees.
3. The mean of vectorial deviation of the measured mean of unbalance after the number of measurements exceeded
9.
4. The maximum vectorial deviation of the measured mean of unbalance after the number of measurements exceeded
9.
Description:
Mount an unbalanced wheel on the shaft.
Set code C63 and low the wheel guard to carry out continuous measurements.
Minor unbalance readings are not suppressed, but read out in high resolution. For readings in gram the amount of
unbalance is read out in ! oating point format.
After the " rst measuring run the Option key can be pressed to switch over readings (see options). The original reading
is restored the third time the Option key is pressed.
The following values can be read out successively by pressing the Special function key:
1. Number of measurements carried out during the test with code C63.
2. The mean of unbalance plus angular location in degrees of the measurements carried out so far, whereby the plane
is signalled by the direction indicator (inner side).
3. The mean of unbalance plus angular location in degrees of the measurements carried out so far, whereby the plane
is signalled by the direction indicator (outer side).
4. The mean of vectorial deviation of the measured mean of unbalance after the number of measurements exceeded
9.
5. The maximum vectorial deviation of the measured mean of unbalance after the number of measurements exceeded
9.
After pressing the Special function key a " fth time the number of measurements carried out so far will be shown again.
By pressing the Option key the standard display of values is selected again.
Comments: The options and the special functions are still available after braking the measuring run with the STOP
key. The angular position of the unbalance will be indicated. The C-Code will be exited by pressing the STOP key a
second time.
C64 Indication of the transducer sensitivity as measured with code C83/C115
Options: None
Special function: None.
Description: The readings refer to ampli" cation factors which were determined during the latest calibration of
unbalance measurement using code C83 or C115. The higher the sensitivity of the transducer, the lower is the
ampli" cation factor. Press the Option key to switch over between rear and front transducer.
The ampli" cation factors must be as follows:
Rear transducer: 595-950
Front transducer: 25-135
Comments: The shown values are those ones calculated in the latest calibration performed.
