Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
114/168
008831 en 2020.10
Installation instructions
Electric motor
Motor
Column 10 Column 11
IEC ∆x motor M
Motor weight from motor data sheet + 40 kg for
motor support
180 241.5
See column 1 in Table 29
and column 10 in Table 31
200 266.5
x =x flange - ∆x motor
225 304.5 See column 2 in Table 29
250 323.5
y
=Yg motor
280 374 See column 3 in Table 29
315 419
z
=zg motor
Fixed values
Calculated and/or edited values
Table 31
Electrical cabinet
Only SABflex
compressor
M
X
x from dimension
sketch or
use default
Y Z
kg
mm mm mm
VLT
125 -430
-45
1250
Electrical cabinet
50 -462 490 1320
Table 32
M X Y Z
M*X M*Y M*Z
kg
mm mm mm
kg*mm kg*mm kg*mm
Separator
747 1075 466 520
967,500
419400 468000
Various 49 733 1000 914
35,917 49,000 44,786
Oil 120 934 702 320
112,080 84,240 38,400
See
Table 29
Compressor
1206 2080 457 1358
2,508,480 551,142 1,637,748
See
Table 31
Motor 1140 800 377 1323
912,000 429,780 1,508,220
See
Table 30
Oil filter 1
lower
126 256 -147 210
32,256 -18,522 26,460
See
Table 30
Oil filter 2
upper
0 256 -147 605 0 0 0
See
Table 30
Oil cooler 63 1720 -172 422
108,360 -10,836 26,586
See
Table 30
Oil pump
0 2440 140 450 0 0 0
See
Table 32
SABflex VLT 0 -630 -45 1250 0 0 0
See
Table 32
SABflex
electrical
cabinet
0 -662 490 1320 0 0 0
3604
4,676,593 1,504,204 3,750,200
Fixed values
Calculated and/or edited values
Table 33
