3.2.9 Electrical Data
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
(H,Y)IC4012B21S
208/230 1 60 253 188
0.4 15 0.057 0.3
(H,Y)IC4015B21S 0.5 15 0.057 0.4
(H,Y)IC4018B21S 0.9 15 0.057 0.7
(H,Y)IC4024B21S 0.9 15 0.057 0.7
(H,Y)IC4030B21S 1.1 15 0.127 0.9
(H,Y)IC4036B21S 1.2 15 0.127 1.0
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
OPT: Rated Motor Output (kW)
FLA: Full Load Ampacity (A)
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
